Coating with HPL laminate
Protection, Aesthetics, Performance.
ALUXAPP panel with HPL laminate applied directly onto the aluminum skins.
The laminate can be applied on both or only one of the aluminum surfaces of the panel. An acrylic resin is used for its application, ensuring the total absence of surface defects.
HPL laminate
CUSTOMER REQUIREMENTS
& ENGINEERING
Stratigraphic study →
Frame Integration →
Edging →
Coating with laminate
CNC machining →
Tool insertion →
Acrylic adhesive
Aluminum alloy 5005
Two-component adhesive
Aluminum honeycomb
Aluminum honeycomb
ALUXAPP coated with HPL laminate
on both sides
ALUXAPP-L panels with symmetrical surfaces are ideal for doors or interior partitions.
Both sides are coated with HPL laminate, giving the panel a high-quality finish. It is possible to insert a layer of cork to increase acoustic and thermal insulation.
Aluminum 5/10 + HPL from 6 to 9/10
upper facade
ALUXAPP-HPL
with symmetrical facades
lower facade
Aluminum 5/10 + HPL from 6 to 9/10
ALUXAPP coated with HPL laminate
on one side only
ALUXAPP-HPL panels with non-symmetrical surfaces are ideal for boiserie panels or false ceilings.
The visible side is covered with an HPL laminate sheet that gives the panel a high-quality finish, while the non-visible side is made of primed aluminum. It is possible to insert a layer of cork to increase acoustic and thermal insulation.
upper facade
Aluminum 5/10 + HPL from 6 to 9/10
ALUXAPP-HPL
with NON-symmetric facades
Aluminum 10/10
lower facade
ALUXAPP- HPL Dimensions
X
Standard panels
The panels can be supplied in standard sizes
with thickness on request.
Standard laminate sizes in mm:
1300 x 3050
1600 x 4200
Y
Custom panels
The ALUXAPP-HPL panel can be supplied in custom sizes
Do you have
a specific requirement?
Talk to one of our engineers to define the door panel configuration best suited to your application.
